| Motherboard Support |
Mini-ITX, Micro-ATX, ATX, and EATX (Up to 272mm) |
| Enclosure Type |
Mid-Tower |
| Case Material |
SGCC Steel, Tempered Glass |
| Fan Support |
| Front |
3 x 120mm / 3 x 140mm |
| Top |
3 x 120mm / 2 x 140mm |
| Rear |
1 x 120mm / 1 x 140mm |
| Filters |
All Air Intakes |
| Dimensions |
| Height |
505mm (With Feet) |
| Width |
230mm |
| Depth |
480mm |
| Weight |
11.36 kg |
| Radiator Support |
| Front |
Up to 360mm with Push/Pull |
| Top |
Up to 360mm |
| Rear |
Up to 140mm |
| Compatibility & Clearance |
| Max CPU Cooler Clearance |
Up to 185mm |
| Max GPU Clearance |
Up to 400mm |
| Front Radiator Clearance |
60mm |
| Top Radiator Clearance |
30mm |
| Cable Management |
18-22mm |
| Model Number |
CM-H71EW-01 (White) |
| Fan Specs |
| Model |
F140Q (Case Version) |
| Speed |
1200 ± 240RPM |
| Airflow |
99.56 CFM |
| Static Pressure |
1.14 mm-H2O |
| Noise |
24.18 dBA |
| Fan Connector |
3-pin |
| Front I/O Ports |
| USB 3.2 Gen 1 Type-A |
2 |
| USB 3.2 Gen 2 Type-C |
2 |
| Headset Audio Jack |
1 |
| Fan Specs |
| Model |
F140 RGB |
| Speed |
500 – 1800 RPM |
| Airflow |
24.85 – 89.48 CFM |
| Static Pressure |
0.94 – 3.39 mm-H2O |
| Noise |
20 – 32.5 dBA |
| Fan Connector |
4-pin |
| RGB and Fan Controller |
| Fan Channels |
3 |
| NZXT RGB Connector |
6 (Support up to 120 LEDs) |
| Expansion Slots |
| Standard |
7 |
| Vertical |
0 |
| Drive Bays |
| 2.5″ |
4+2 |
| 3.5″ |
2 |
| Warranty |
2 Years |
*Note: The actual colours may be different from the colour displayed here. Features, Price and Specifications are subject to change without notice.
