Overview
The RGB Duo Fans strike a balance between bright style and performance with twenty individually addressable RGBs and high static pressure.
- Enjoy vibrant RGB lighting from all angles with 20 individually addressable LEDs
- Fan blade design deliver the optimal balance between airflow and high static pressure ideal for use anywhere in a PC
- Fluid Dynamic Bearing (FDB) ensures smooth and quiet operation with a long lifespan
- Rubber dampeners on the corners reduce vibration noise
- PWM fan control means fans cool quickly when needed, but stay quiet at lower loads for maximum efficiency
- Mix and match with NZXT F120/F140 RGB fans
- Personalize RGB lighting effects and configure fan speeds with NZXT CAM
Tech Specs
| Specification |
Details |
| Material |
Plastic, Rubber, PCB |
| Fan Rated Voltage |
12V DC, 0.13A, 1.56W |
| LED Quantity |
20 |
| Bearing |
Fluid Dynamic Bearing (FDB) |
| Fan Connector |
4-pin PWM |
| Dimensions (H × W × D) |
120 × 120 × 25 mm |
| Speed |
500 €“ 1,800 ± 300 RPM |
| Airflow |
50.00 CFM |
| Static Pressure |
2.60 mm-H‚‚O |
| Noise |
31.0 dBA |
| Fan Life (Hours) |
60,000 |
| Fan Life (Years) |
6 |
| RGB Controller Dimensions |
63.2 × 53.2 × 12.8 mm |
| Weight |
52.8 g |
| Controller Material |
Plastic, PCB, Magnets |
| Mounting |
2× 3M Dual Lock |
| Connections |
1× USB 2.0 Header, 1× SATA |
| Input Connector |
12V DC / 2.6A |
| Output Channel Voltage |
5V DC |
| RGB Lighting Channels |
3 |
| Lighting Channels Support |
Up to 40 LEDs per channel (120 total) |
| System Requirement |
PC with NZXT RGB connector, Windows 11/10 |
| Internal Connector |
USB 2.0 internal connector required |
| Warranty |
2 years |
